Specification:
| Product name |
HDMI AOC Cable 100M 4K 3D HDMI cable AOC Fiber Optic HDMI cable support 18.2Gbps and 60Hz |
| keyword | 4K Optical fiber HDMI cable |
| Plug | 19-pin male to male |
| Outer Jacket | PVC Jacket |
| Conductor | oxygn-free copper |
| Connector | 24K Gold plated |
| Resolution | 18Gbps 4K@120Hz |
| Certification | CE, FCC, RoHS, HDMI adopter |
| Material | optic cable + Bare coppe OD:5.0mm |
| Length | 2m to 300m |
Electrical:
| Quality Control | 100% open and short test, 216P, 8K 60Hz and 3D test |
| Voltage | DC 300V 5MΩ /10ms |
| Insulation resistance | 10M minimum |
| Contact resistance | 2Ω Maximum |
| Working temperature | -25° C - 80° C |
| Data transfer rate | 18Gbps maximum |
| Differential impedance | 100± 10Ω (TDR) |
Features and structure of HDMI AOC cable:
- HDMI AOC cable is a hybrid active optical fiber composed of four multimode fiber and seven copper cables
- Can directly transmit high resolution, lossless 4K@120HZ ultra-high-definition video directly
- Center conductor: high quality digital signal delivered by oxygen-free copper
- Insulation: Using foamed PE as the insulation, ensure image quality and transmit image signal with stability
- Inner shield: 100% Aluminum/Mylar foil shield, prevent high frequency noises and interference
- Outer shield: 95% copper braid shield, prevents most low frequency noises and interference
HDMI 2.0 AOC Cable 100M 4K 3D HDMI cable AOC Fiber Optic HDMI cable support 18.2Gbps and 60Hz
HDMI 2.0 AOC Cable 100M 4K 3D HDMI cable AOC Fiber Optic HDMI cable support 18.2Gbps and 60Hz
HDMI 2.0 AOC Cable 100M 4K 3D HDMI cable AOC Fiber Optic HDMI cable support 18.2Gbps and 60Hz
